GPS Tracking Devices



Hybrid Tracker

ASI brings a tracking solution which supports both Sigfox and LTE connectivity.

Product Summary

  • Dimensions: 72mm (L) x 32mm (W) x 15mm (H)

  • Weight: 40g

  • Connectivity: Sigfox/LTE/GSM

  • Network Bands: Support as required by region

  • Chipset: GCT7243i

  • GPS Chipset: UBLOX

  • Positioning Accuracy: 10 meters (affected by weather, environment, location and other factors)

  • GPS sensitivity: -163dBm

  • start-up time: cold start 35 seconds, AGPS start 25 seconds, hot start 1 second

  • Power: Lithium battery 500ma

  • Standby duration: 180 days (Sigfox)  /5 days (LTE/GSM)

  • Stored temperature: -40°C  to  +85°C

  • Operating temperature: -20°C  to  +55°C

  • Humidity: 5%-95% non-condensing



Sigfox Tracker

ASI brings to you a solution that is simple, yet flexible to meet your asset tracking needs.

Product Summary

  • Cost effective

  • Multi-regional support

  • Embedded Innocomm module (SN10-22) offers flexible provisioning choices

    • Sigfox only radio

    • GPS

    • Bluetooth

    • WiFi

    • Accelerometer

  • Optional field replaceable lithium battery



GSM GPS Tracking

This is a compact solution for GSM GPS based tracking of assets.

Product Summary

  • Dimensions: 50mm (L) x 40mm (W) x 23mm (H)

  • Weight: 40 grams

  • Connectivity: GSM/GPRS

  • Network Bands: 800/900/1800/1900Mhz

  • Chipset: MTK6260D

  • GPS Chipset: UBLOX

  • Accuracy: 10 Meters (affected by weather, environment, location, and other factors)

  • GPS Sensitivity: -159 dBm

  • Start-up Time: cold start 45-120 seconds, warm start 35 seconds, hot 1 second

  • Power: Lithium Battery 500 ma (Stand By 5 days)

  • Stored Temp: -40 C to +85 C

  • Operating Temp: -20 C to +55 C

  • Humidity: 5% - 95% non-condensing



Soil Sensor

Product Info

  • Transmission Mode: Sigfox

  • Support Area: RCZ1/RCZ2/RCZ4

  • Transmission Speed: 600bps

  • Output power: 22dBm

  • Transmission distance: 1000m

  • Power: 3.6V lithium battery

  • Life: Half a year (Send a data for 1 days )

  • Temperature range: 0~50Ⅸ

  • Temperature accuracy: Ñ1Ⅸ

  • Moisture range: 0~99%

  • Moisture accuracy:

    • ±10% @0~40%

    • ±20% @40~99%

  • Response time: <1s

  • Shell protection grade: IP65

  • Working temperature: -10~60Ⅸ

  • Storage temperature: -10~60Ⅸ

  • Probe material: Food grade stainless steel

Smart ID Badges

Product Info

  • NFC Type A – Active RFID

  • Bluetooth 5.0 –up to 30 meters

  • Sigfox (RCZ 1,2,3,4)

  • PANIC Button

  • IPX2

  • Dimension (mm): 54 X 86 X 6

  • Power: Rechargeable battery – 700mA - micro USB charger

  • Duration: 1+ Year for Panic only mode, 1+ Month for tracking mode

  • Optional

    • Temperature sensor

    • Accelerometer

    • Humidity sensor

eHealth Devices

We provide flexible and dependable solutions for the healthcare industry.



3g Smartphone with Glucose meter

Product Info

  • Cellular Specifications

    • Dimensions (mm ): 121 x 65.2 x12.4

    • Weight: 136g

    • Display: 4.0’’ 480x800 WVGA TFT LCD with capacitive touch panel

    • Battery (removable/non-removable): removable, 1800mAh

    • Chipset (modem/AP): Qualcomm 8610

    • Bands/Modes: GSM850/900/1800/1900, WCDMA B1, B5

    • Operating system: Android 4.4

    • Storage (ROM/RAM, external): 4GByte+4Gbit, support Micro SD card

    • Rear/Front facing camera (MP, AF): 5M/FF+2M/FF

  • Glucose Meter Specifications

    • Test range: 1.1~33.3mmol/L

    • Minimum sample: 0.8 microliters

    • Test time: <10S

    • Hematocrit range: 30 - 55%

    • Memory: 10k blood test results

    • Operating Temp: 10℃ - 40 ℃

    • Relative humidity: <85%

    • Auto speech

    • FDA certificated





LTE SMartphone with Glucose meter

Product Info

  • 2.8” WVGA LCD

  • Qualcomm MDM9206 LTE Cat M (Q3’18)

  • With SigFox (Build on request)

  • Linux 3.0

  • Band (Verizon) - LTE: 2/4/13

  • Dimensions (mm): 105 x 59 x 12.4

  • Weight (g): 80 g

  • Camera 2M

  • Memory: 4GB/512MB

  • Wi-Fi: 2.4GHz

  • BTLE 4.1

  • Battery size: 1200mAh

  • GPS

  • Micro USB

  • 3.5mm ear jack

  • BGM 1.8
